WyreStorm MX-0804-EDC
8×4 HDMI Seamless Matrix Switch with USB-C, Audio DSP and Dante
7 × HDMI, 1 × USB-C inputs; 4 × HDMI outputs; USB Hub, Audio Amp, Scaling
Availability: Please Call
WyreStorm MX-0804-EDC
The Wyrestorm MX-0804-EDC is a compact 1RU 8×4 fast switching matrix designed to redefine connectivity in professional environments. Perfect for high-education classrooms and corporate meeting rooms, this cutting-edge matrix brings seamless transitions, versatile audio options, and intuitive control at your fingertips.
4K60Hz SEAMLESS SWITCHING
Effortlessly transition between video inputs with crystal-clear visuals. The built-in 4K60 scaler ensures a smooth, uninterrupted visual experience, making it ideal for presentations and entertainment.
FULL-FEATURED USB-C INPUT
Stay connected and charged with the fully-featured USB-C input supporting 4K@60Hz, USB 3.1 gen1, 1G network, and PD 3.0 charging up to 60 watts. Streamline your connectivity and charging needs in one port.
VERSATILE AUDIO CONNECTIONS AND DSP
Immerse yourself in high-quality audio with Analogue microphone inputs, Dante 4×4 digital I/O, USB audio, and line audio outputs. The integrated DSP optimizes sound quality, offering independent mixers and ducking for a customized auditory experience.
BUILT-IN POWER AMPLIFIER FOR DIRECT SPEAKER DRIVE
The matrix features a built-in power amplifier capable of directly driving a pair of stereo speakers (25 Watts per channel @ 4Ω or 8Ω). Streamlined audio setup with the ability to power stereo speakers directly from the matrix. The internal amplifier synergizes seamlessly with the onboard DSP, ensuring optimal audio quality for a rich and immersive auditory experience.
WyreStorm MX-0804-EDC Key Features
- Multi-format video connections include USB-C and HDMI
- Sygma Cloud Monitoring Ready
- Each output supports fast switching and is equipped with a full 480p-2160p scaler
- USB-C input supports up to 4K60 video, USB3.0/USB2.0, 1G network, and PD3.0 USB host charging up to 60 watts
- HDBaseT outputs support 3.0 specification for uncompressed A/V, USB and control
- Equipped with a full DSP including Dante 4×4, mic inputs, balanced audio outputs and two 4-channel amplifier
WyreStorm MX-0804-EDC Downloads
WyreStorm MX-0804-EDC Specifications
Connectivity |
|
| Inputs | 1 × USB-C In with Alt-Mode |
| 7 × HDMI In on 19-pin type A | |
| 2 × USB-B Host | |
| 2 × Mic in | |
| 1 × Line-In | |
| Outputs | 4 × HDMI Out on 19-pin type A |
| 4 × USB-A Device | |
| 1 × GPIO Phoenix Port | |
| 2 × Relay Phoenix Port | |
| 2 × Line-Out | |
Processing |
|
| Audio Formats | PCM 2ch Analogue, Dante 4×4 |
| Video Resolution (Max) | 1920 × 1080p @60Hz |
| 3840 × 2160p @60hz 4:2:0 | |
| 3840×2160p @60hz 4:4:4 | |
| Max Pixel Clock | 600MHz |
| Supported Standards | DCI (4096×2160), RGB, HDR, HDR10, Dolby Vision, HLG, BT.2020 |
Control |
|
| HDMI | HDMI 2.0, HDCP 2.3, EDID, CEC |
| Dante Ultimo 4×4 | 1 × 1GbE RJ45 |
| RS-232 | 1 × RS-232 3-pin Phoenix Female, Matrix Control, Telnet commands supported |
| HDCP | Pass-Through, 2.3 Supported |
| Ethernet | 2 × Lan on 8-pin RJ45 Female, Web UI, Matrix Control and Ethernet (Sygma) |
Mechanical |
|
| Power Supply | 100~240V AC 50/60Hz |
| Max Consumption | 7.8W |
| PoH | Supported, 1-way from RX |
| Local Power Supply Input | 4-pin Phoenix |
| Operating Temperature | 0 to + 45°C (32 to + 113 °F), 10% to 90%, non-condensing |
| Storage Temperature | -20 to +70°C (-4 to + 158 °F), 10% to 90%, non-condensing |
Dimensions |
|
| Rack Units/Wall Box | 1U |
| Height | 43mm/1.7in |
| Width | 440mm/17.33in |
| Depth | 330mm/12.99in |
| Weight | 3.8kg/8.38lbs |
WyreStorm MX-0804-EDC Optional Cables
| Description | Length | Price | Inc. VAT | |
| WyreStorm EXP-4KUHD-0.5 High-speed 18Gbps 4K HDMI with HDR support | 0.5m | £13 | £15.60 | |
| WyreStorm EXP-4KUHD-1.0 High-speed 18Gbps 4K HDMI with HDR support | 1.0m | £15 | £18.00 | |
| WyreStorm EXP-4KUHD-2.0 High-speed 18Gbps 4K HDMI with HDR support | 2.0m | £17 | £20.40 | |
| WyreStorm EXP-4KUHD-3.0 High-speed 18Gbps 4K HDMI with HDR support | 3.0m | £22 | £26.40 | |
| WyreStorm EXP-4KUHD-5.0 High-speed 18Gbps 4K HDMI with HDR support | 5.0m | £45 | £54.00 | |
| WyreStorm CAB-HAOC-10 24Gbps Active Optical HDMI (2K/4K/5K; HDR-10, HDR-10+; ARC; HDCP 2.3) | 10.0m | £154 | £184.80 | |
| WyreStorm CAB-HAOC-15 24Gbps Active Optical HDMI (2K/4K/5K; HDR-10, HDR-10+; ARC; HDCP 2.3) | 15.0m | £168 | £201.60 | |
| WyreStorm CAB-HAOC-15-C 24Gbps Active Optical HDMI with detachable head (2K/4K/5K; HDR-10, HDR-10+; ARC; HDCP 2.3) | 15.0m | £186 | £223.20 |
WyreStorm MX-0804-EDC Possible Alternatives
| Product Code | Description | Price | Inc. VAT |
| Kramer VS-84H2 | 8 × 4 4K HDMI 2.0 HDR Matrix Switcher8 × HDMI inputs; 4 × HDMI outputs; Max. bandwidth 18Gbps | £2779 | £3334.80 |
| Kramer VS-84UT | 8 × 4 4K60 4:2:0 HDMI / HDBaseT 2.0 Matrix Switcher and Master Room Controller with PoH & Power Amplifier 6 × HDMI, 2 × HDBaseT 2.0 inputs; 2 × HDMI, 2 × HDBaseT 2.0 outputs; Max. bandwidth 10.2Gbps | £4716 | £5659.20 |
| Lightware MMX8x4-HT400MC | 8 × 4 HDMI and HDBaseT Matrix Switcher 4 × HDMI, 4 × HDBaseT inputs; 4 × HDMI outputs | £4670 | £5604.00 |
| Lightware MMX8x4-HT420M | 8 × 4 HDMI and HDBaseT Matrix Switcher 4 × HDMI, 4 × HDBaseT inputs; 2 × HDMI, 2 × HDBaseT outputs | £6840 | £8208.00 |
