Panasonic PT-MW630LEJ Optical Features
|
System |
3 * 0.76" LCD |
Resolution |
WXGA (1280*800) |
Aspect Ratio |
16:10 |
ANSI Lumens |
6500 |
Colour Light Output |
6500 Lumens |
Contrast |
3000000:1 |
Lamp |
Laser Diode |
Lamp Life |
10000hrs. (20000hrs. ECO mode) |
Lens |
Click for optional lenses |
Interchageable |
No |
Lens Shift |
Ver.±67%; Hor. ±35% |
Keystone Correction |
±35° (Vertical) |
|
±35° (Horizontal) |
Panasonic PT-MW630LEJ Compatibility
|
Computer Resolutions |
FHD, WUXGA, UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac |
Video Resolutions |
1080p, 1080i, 720p, PAL, SECAM, NTSC |
Horizontal Freq. |
15-91kHz |
Vertical Freq. |
24-100Hz |
Panasonic PT-MW630LEJ Terminals
|
HDMI |
2 |
RGBHV (15-pin HD) |
1 |
RGBHV (BNC/RCA) |
1 |
Composite |
1 |
Monitor Out |
Yes |
Audio In |
3 |
Audio Out |
1 |
USB |
2 |
RS-232 |
2 |
Network Ready |
Yes |
Panasonic PT-MW630LEJ General
|
Speakers |
10w Mono |
Remote Control |
Panasonic PT-MW630LEJ only |
Noise |
32db (26db ECO mode) |
Dimensions |
560*205*443mm (W*H*D) |
Weight |
16.90kg |
Power Supply |
100-240V AC; 50-60Hz |
Power Consumption |
505Watts |
Manufacturers Warranty |
Not Quoted |
Light Source Warranty |
90 Days/1000 hours (whichever first) |
