WyreStorm TS-280-EU
2.8" Serial Control Colour Touchscreen for WyreStorm presentation switchers
£260 (£312.00 inc. VAT)
Availability: Please Call
Availability: Please Call
WyreStorm TS-280-EU
The WyreStorm TS-280-EU 2.8” colour touchscreen can control any product within the WyreStorm presentation switcher range. With ease of use in mind the TS-280 is as easy to use as it is to set up, with pre-configured UI's ready to upload in just seconds via the MicroSD card slot on the rear.
The UI's are simple to use with large buttons clearly labeled for each major function and navigation controls (where applicable) to move between pages. Using a standard RJ45 connection on the rear and RS-422 communication, the TS-280 also comes with an in-line RS-422 to RS-232 converter which doubles as a power-injector if used with a product that doesn't feed the 12v power.
WyreStorm TS-280-EU Key Features
- TOUCHSCREEN INTERFACE — Instantly identified as a simple control interface yet giving the appearance that a sophisticated control system is behind the scenes, the 2.8” touchscreen simplifies matters by firstly removing the expensive processor within a control system and secondly sending serial commands directly to the switcher via Cat5e cable
- INTUITIVE & SIMPLE USER CONTROL — Why use a sledge hammer to crack a walnut When a full control system processor is considered over-kill for a small classroom or meeting space, the TS-280 has you covered. Aside from the automatic operation of the WyreStorm switcher, basic functions such as switching and CEC triggering can be controlled from this simple interface touch.
- SIMPLE SETUP — The pre-configured UI's for the TS-280 align with all WyreStorm presentation switcher products, offering a quick & easy solution when manual control of the meeting or education space is required. Once downloaded from the website, the UI file can be uploaded and ready to go in less than 30 seconds.
- EXTENDED RANGE —
- Using RS-422 communication between the touchscreen and the interface module means that even the longest of cable runs can be accommodated; up to 100m/328ft between control point and switcher. Power can either be drawn directly from a compatible switcher or via 12v PSU connected to the interface module.
