Kramer AW-6P (B)
1 × All-weather, IP66/UL rated, 6.5" two-way wall mounted passive speaker finished in Black
8 Ohm or 70V/100V; 30W continuous / 45W Peak
£105 (£126.00 inc. VAT)
Availability: In stock
Availability: In stock
Kramer AW-6P (B) (60-000103)
Kramer's AW Series are engineered to deliver exceptional sound performance in both indoor and outdoor environments. The AW-6P is a compact 6.5” high-performance all-weather passive speaker. This UL compliant/IP66-rated all-weather speaker is designed to withstand the elements while providing clear, high-quality audio, making it the perfect solution for mixed installations, in which some of the speakers are outdoor and other are indoor. The speaker supports both 8Ω low impedance as well as several 70V/100V high impedance modes. The speaker is available in both black & white colours.
Kramer AW-6P (B) Key Features
- IP66 rated for outdoor installations
- UL1480A compliant for indoor installations, made from V-0 Flame Retardant materials
- Exceptional sound performance
- Low-impedance (8Ω) / high-impedance (70V/100V)
- Power handling: 30 W continuous / 45 W peak
- Sensitivity (1W@1m, free field): 87dB SPL
- Maximum SPL (@1m): Continuous: 102dB SPL / Peak: 104dB SPL
- Industrial design: wall-mounted, tool-less installation, available in black & white colours, removable logo
- Included in the Box — 1 speaker (single unit), 2 speakers are packed in a single master box
- 1 mounting bracket + 2 tool-less bracket screws
- 4–pin pluggable Euroblock connector, 28–12AWG
- Quick Start Guide
- 7 year warranty (Click Here for details)
- Order Code: 60-000103
Kramer AW-6P (B) Downloads
Kramer AW-6P (B) Specifications
Audio |
|
| LF Driver | 165 mm (6.5”) driver with polypropylene cone and rubber surround |
| HF Driver | 25mm (1") soft dome with dampening, ferrofluid - cooled |
| Frequency Range(-10db) | 75Hz-20kHz |
| Frequency Response (±3db) | 89Hz-20kHz |
| Dispersion Angle | 132 ° conical dispersion (1 kHz to 4 kHz) |
Power ratings |
|
| @ 8W Low Impedance | 30W continuous / 45W peak |
| @ 100 V High Impedance | 30W/15W/7.5W |
| @ 70 V High Impedance | 30W/15W/7.5W/3.8W |
Sound Pressure Level (SPL) |
|
| Sensitivity (1w@1m, Free Field) | 87dB SPL |
| Maximum Spl | Continuous: 102dB SPL / Peak: 104dB SPL |
Mechanical |
|
| Type | Surface mounted vertical or horizontal |
| Mounting | Mounting bracket with toolless bracket screws |
| Connectors | 4-pin pluggable Euroblock connector, 28-12AWG |
| Weight Per Single Speaker | 3.15kg / 6.94lbs |
| Dimensions | 201mm × 168mm × 320mm / 7.9” × 6.7” / 12.6” |
| Without Bracket | |
| Dimensions | 201mm × 205mm × 320mm / 7.9” × 8.1” / 12.6 |
| With Bracket | |
| Shipping Dimensions | 287mm × 235mm × 385mm / 11.3" × 9.3" × 15.2" |
| Single Unit | |
| Shipping Dimensions | 477mm × 296mm × 403mm / 18.8” × 11.7” × 15.9” |
| 2 Units In A Master Box | |
| Shipping Weight | 3.7Kg / 8.2lbs (Single Unit) |
| Shipping Weight | 8Kg / 17.6lbs (Master Box) |
Material |
|
| Grill | Aluminium, removable logo |
| Baffle | V-0 Flame Retardant |
| Baffle & Back Enclosure | V-0 Flame Retardant |
| Bracket | Aluminium |
Environmental |
|
| Operating Temperature | -5° to +50°C (23° to 122°F) |
| Storage Temperature | -10° to +55°C (14° to 131°F) |
| Humidity | 30% to 85%, RHL non-condensing |
REGULATORY |
|
| Ul1480a Certified | UL 1480A compliant - Safety standards for fire-protective signaling in commercial spaces |
| Environmental | RoHS, REACH, WEEE |
| IP Rating | IP66 |
| In The Box | 1 speaker (single unit), 2 speakers are packed in a single master box |
| 1 mounting bracket + 2 toolless bracket screws | |
| 4-pin pluggable Euroblock connector, 28-12AWG | |
| Quick Start Guide | |
